Slewing Ntiv nplhaib Bearing

Cov plaub-point sib cuag pob turntable bearing feem ntau yog tsim los ntawm sab hauv thiab sab nrauv, ib kab ntawm cov pob hlau, lub tawb (los yog cais), thiab cov khoom sib khi. Cov rings sab hauv thiab sab nrauv tuaj yeem yog ib qho lossis cov qauv sib cais. Integral rings muaj qhov muaj zog rigidity, thaum sib cais cov qauv muab kev hloov kho yooj yim dua; ob lub nplhaib sib cais yog bolted ua ke ua ntej tawm hauv lub hoobkas.

Feem ntau, plaub-point sib cuag pob bearings muaj xws li lub tawb (los yog cais). Ib lub pob tag nrho tsuas yog siv nyob rau hauv cov xwm txheej hnyav, vim nws muaj peev xwm ntau dua, tab sis kuj muaj kev sib txhuam ntxiv, uas tuaj yeem ua rau khawb ntawm cov pob hlau.

Cov qauv tsim ntawm plaub-point sib cuag pob turntable bearings / slewing rings muaj xws li tsis-geared, sab nraud geared, thiab sab hauv geared hom, tag nrho cov uas muaj ib tug kuj zoo li qub load peev xwm.

Table of Gear Basic Parameters

Qauv	Hniav Profile Hom	Module (m)	Cov hniav (Z)	Lub kaum sab xis siab ( )	Ntxiv Coefficient (h)	Profile Hloov Coefficient (x)
TEC - 150P750SP	Involute	1.5	110	20 degree	1.0	0
TEC - 167P400SP	Involute	Tsis qhia meej	114	20 degree	1.0	0
TEC - 167(V2.1)	Involute	3	40	20 degree	1.0	0
TEC - 300	Involute	2.5	127	20 degree	1.0	-0.28
TEC - 410	Involute	2.5	180	20 degree	1.0	-0.28



Table of Span thiab Deviation Related Parameters

Qauv	Tshaj	Tus naj npawb ntawm cov hniav ntsuas hla (K)	Upper sib txawv (Es)	Kev sib txawv qis (Es)
TEC - 150P750SP	57.66	13	Tsis muaj qhov cim meej meej (yuav tsum yog mm raws li cov ntsiab lus)	Tsis muaj qhov cim meej meej (yuav tsum yog mm raws li cov ntsiab lus)
TEC - 167P400SP	7.9	13	-0.198	Chav tsev tsis qhia meej tab sis yuav tsum yog mm raws li cov ntsiab lus
TEC - 167	87.83	12	-0.320	Tsis muaj qhov cim meej meej (yuav tsum yog mm raws li cov ntsiab lus)
TEC - 300	103.6	14	Tsis muaj qhov cim meej meej (yuav tsum yog mm raws li cov ntsiab lus)	Tsis muaj qhov cim meej meej (yuav tsum yog mm raws li cov ntsiab lus)
TEC - 410	14.74	20	Sab saum toj sib txawv cov ntaub ntawv tsis tau hais meej meej (lub npe hauv cov lus yog Etes Wk Ebei, txawv ntawm lwm tus)	Kev sib txawv qis dua cov ntaub ntawv tsis tau hais meej meej (lub npe hauv cov lus yog Etes Wk Ebei, txawv ntawm lwm tus)



Table of Precision Related Parameters

Qauv	Ib Hniav Pitch Deviation (± f pt)	Qhov sib txawv ntawm qhov sib txawv (Fp)	Hniav Profile Evaluation Range	Tag nrho cov hniav Profile Deviation (Fa)	Helix Evaluation Range	Tag nrho Helix Deviation (F)	Radial Runout (F)
TEC - 150P750SP	±0.012	0.049	Tsis muaj qhov cim meej meej (yuav tsum yog mm raws li cov ntsiab lus)	0.014	Tsis muaj qhov cim meej meej (yuav tsum yog mm raws li cov ntsiab lus)	0.016	0.039
TEC - 167P400SP	±0.024	0.098	9.30	0.028	17	0.032	0.078
TEC - 167	±0.026	0.036	14.03	0.100	13.10	0.032	0.080
TEC - 300	±0.029	0.131	11.39	0.041	19	0.034	0.105
TEC - 410	±0.029 (xav tias ±f cheeb tsam yog ±f pt)	0.131	11.75	0.041	23.75 (kwv yees li LA yog L)	0.038	0.105 (xav tias Fy yog F )



Daim ntawv thov

Forklift AGVs:
Kev ua haujlwm ib puag ncig ntsib los ntawm forklift AGVs yog qhov nyuaj. Yog li ntawd, slewing bearing rau AGVs (Automated Guided Vehicles) siv rau ntawm lub log tsav tsheb kuj xav tau kev ruaj ntseg zoo dua, thiab qhov saum npoo kuj xav tau kev kho mob tshwj xeeb rau lub ntsej muag tshwj xeeb.

CT:
Thaum lub sijhawm ua haujlwm ntawm lub tshuab CT, lub raj X-ray thiab lub ntsuas ntsuas tig ncig tus neeg mob ib txhij. Qhov no tuaj yeem tsim cov duab hla ntu. Los ntawm lawv, cov kws kho mob tuaj yeem tau txais cov ntaub ntawv tseem ceeb rau lawv qhov kev kuaj mob.
Nyob rau hauv cov txheej txheem kev sib hloov ceev ntawm lub tshuab CT, txhawm rau ua kom muaj kev kho mob nyob ntsiag to, suab nrov thiab kev ua haujlwm siab-precision slewing bearings (turntable bearings) rau cov khoom siv kho mob yog qhov tseem ceeb heev.



Kev Tsim Nyog Kev Tsim Nyog



Pab pawg muaj zog Technical

Efficient Structural Design

Kev paub ntau lawm Pab Pawg 1

Kev paub ntau lawm pab neeg 2

Cov txheej txheem tswj kev ua tau zoo

Tuam Txhab Txheej Txheem



FAQ



Q: Lub slewing bearing ua li cas?

A: Slewing bearings suav nrog lub nplhaib puab thiab lub nplhaib sab nraud, ib qho ntawm cov khoom siv feem ntau suav nrog lub iav. Ua ke nrog cov qhov txuas hauv ob lub nplhaib, lawv ua kom muaj kev sib kis tau zoo tshaj plaws nrog kev sib txuas yooj yim thiab nrawm ntawm cov khoom siv tshuab uas nyob ib sab.

Q: Dab tsi yog qhov kev siv ntawm slewing bearings?

A: Slewing bearings pab thiab pab txhawb kev sib hloov ntawm cov cua turbines, excavators, cranes thiab tunnel tho txawv tshuab, tsuas yog rau npe rau ob peb tug.

Q: Kuv yuav xaiv lub slewing bearing li cas?

A: Ntau qhov kev thov yuav tsum muaj feem cuam tshuam rau kev xaiv qhov tsim nyog slewing bearing. Cov kev xav no suav nrog, ntawm lwm tus, kev sib hloov ceev, kev tiv thaiv los ntawm kev sib kis, qhov tseeb, kev sib txhuam tsis kam, thiab qhov kub thiab txias ntawm qhov chaw ua haujlwm.
